The 17 HMR is the fastest rimfire cartridge in production, and this chart gathers every factory load the major makers publish with downrange figures. Nineteen distinct loads from six brands are charted below, with bullet weights from 15.5 to 20 grains and muzzle velocities from 2,375 to 2,650 fps. Each maker prints its own distance grid, so the loads are grouped by grid rather than forced onto a single one, and every figure is reproduced exactly as published.
Table of Contents [Click to minimize]
17 HMR Ballistics Chart: Federal and Remington Loads to 150 Yards
Federal and Remington print the same grid for their 17 HMR loads: velocity, energy and wind drift at the muzzle, 50, 100 and 150 yards, plus two trajectory sets. The average range set is printed for a 50 yard zero with sights 1.5 inches above the bore line, while the long range set reads zero at 100 yards.
| Brand | Load | Product Line | SKU | Bullet Style | BC (G1) | Vel. Muzzle (fps) | Vel. 50 yd (fps) | Vel. 100 yd (fps) | Vel. 150 yd (fps) | Energy Muzzle (ft-lb) | Energy 50 yd (ft-lb) | Energy 100 yd (ft-lb) | Energy 150 yd (ft-lb) | Wind Drift 50 yd (in) | Wind Drift 100 yd (in) | Wind Drift 150 yd (in) | Avg Range Path 50 yd (in) | Avg Range Path 100 yd (in) | Avg Range Path 150 yd (in) | Long Range Path 50 yd (in) | Long Range Path 100 yd (in) | Long Range Path 150 yd (in) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Federal | Champion BYOB | Champion | 770BTL250 | Jacketed Hollow Point | .110 | 2530 | 2150 | 1804 | 1502 | 242 | 174 | 123 | 85 | 0.9 | 3.8 | 9.4 | 0 | -0.4 | -3.5 | 0.2 | 0 | -2.9 |
| Federal | Varmint & Predator V-Max | Varmint & Predator | P771 | V-Max® | .125 | 2530 | 2194 | 1884 | 1606 | 242 | 182 | 134 | 97 | 0.8 | 3.3 | 8.1 | 0 | -0.3 | -3.1 | 0.2 | 0 | -2.7 |
| Federal | Varmint & Predator TNT | Varmint & Predator | P770 | Speer TNT Jacketed Hollow Point | .110 | 2530 | 2150 | 1804 | 1502 | 242 | 174 | 123 | 85 | 0.9 | 3.8 | 9.4 | 0 | -0.4 | -3.5 | 0.2 | 0 | -2.9 |
| Remington | Magnum Rimfire | Magnum Rimfire | 20023 | Jacketed Hollow Point | .100 | 2550 | 2132 | 1757 | 1434 | 245 | 172 | 116 | 78 | 1 | 4.3 | 10.5 | 0 | -0.4 | -3.7 | 0.2 | 0 | -3.1 |
| Remington | Magnum Rimfire | Magnum Rimfire | 20025 | Jacketed Soft Point | .125 | 2375 | 2051 | 1754 | 1492 | 250 | 187 | 137 | 99 | 0.9 | 3.7 | 8.9 | 0 | -0.6 | -4 | 0.3 | 0 | -3.2 |
| Remington | Magnum Rimfire | Magnum Rimfire | 28464 | AccuTip-V | .125 | 2550 | 2212 | 1901 | 1621 | 245 | 185 | 136 | 99 | 0.8 | 3.2 | 8 | 0 | -0.3 | -3 | 0.1 | 0 | -2.6 |
Six loads are plotted at the distances their makers publish: CCI VNT (959CC), Federal P771, Remington 28464, Winchester S17HMR1, Hornady 83170 and Browning B195117050. The drop panel uses each maker’s published path that reads zero at 100 yards. Browning’s path is zeroed at 50 yards, so it stays in its own table below instead.
Winchester Loads Charted to 200 Yards
Winchester prints the deepest grid of any maker here, stepping in 25 yard increments past 100 yards out to 200. Its path columns are the short range set, which reads zero at 100 yards.
| Brand | Load | SKU | Bullet Style | Bullet Weight (gr) | BC (G1) | Vel. Muzzle (fps) | Vel. 50 yd (fps) | Vel. 100 yd (fps) | Vel. 125 yd (fps) | Vel. 150 yd (fps) | Vel. 175 yd (fps) | Vel. 200 yd (fps) | Energy Muzzle (ft-lb) | Energy 50 yd (ft-lb) | Energy 100 yd (ft-lb) | Energy 125 yd (ft-lb) | Energy 150 yd (ft-lb) | Energy 175 yd (ft-lb) | Energy 200 yd (ft-lb) | Wind Drift 50 yd (in) | Wind Drift 100 yd (in) | Wind Drift 125 yd (in) | Wind Drift 150 yd (in) | Wind Drift 175 yd (in) | Wind Drift 200 yd (in) | Path 50 yd (in) | Path 100 yd (in) | Path 125 yd (in) | Path 150 yd (in) | Path 175 yd (in) | Path 200 yd (in) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Winchester | Super X | X17HMR1 | Jacketed Hollow Point | 20 | 0.130 | 2375 | 2063 | 1776 | 1644 | 1520 | 1406 | 1304 | 250 | 189 | 140 | 120 | 103 | 88 | 75 | 0.8 | 3.5 | 5.7 | 8.5 | 11.9 | 16.1 | 0.3 | 0 | -1.1 | -3.1 | -5.9 | -9.9 |
| Winchester | Varmint HV | S17HMR1 | Polymer Tip | 17 | 0.125 | 2550 | 2212 | 1901 | 1757 | 1620 | 1494 | 1378 | 245 | 185 | 136 | 116 | 99 | 84 | 72 | 0.8 | 3.3 | 5.3 | 8 | 11.3 | 15.3 | 0.1 | 0 | -0.9 | -2.6 | -5 | -8.5 |
| Winchester | Varmint LF | S17HMR1LF | Polymer Tip | 15.5 | 0.115 | 2550 | 2184 | 1850 | 1696 | 1553 | 1422 | 1305 | 231 | 169 | 122 | 102 | 86 | 72 | 60 | 0.8 | 3.6 | 5.9 | 8.9 | 12.6 | 17.1 | 0.2 | 0 | -1 | -2.7 | -5.4 | -9.1 |
CCI and Browning Loads Charted to 100 Yards
CCI and Browning end their printed grids at 100 yards. Where CCI’s chart prints a zero marker symbol instead of a number, the cell shows 0.0, marking the distance where the path crosses the line of sight: 100 yards for five loads and 75 yards for the TNT Green. Browning prints a path only at the muzzle, 50 and 100 yards, and its muzzle figure is -1.5 in, so its 25 and 75 yard path cells are hyphens.
| Brand | Load | SKU | Bullet Style | Bullet Weight (gr) | Vel. Muzzle (fps) | Vel. 50 yd (fps) | Vel. 100 yd (fps) | Energy Muzzle (ft-lb) | Energy 50 yd (ft-lb) | Energy 100 yd (ft-lb) | Path 25 yd (in) | Path 50 yd (in) | Path 75 yd (in) | Path 100 yd (in) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CCI | VNT | 959CC | VNT | 17 | 2650 | 2353 | 2070 | 269 | 209 | 162 | -0.6 | 0.0 | 0.2 | 0.0 |
| CCI | V-MAX | 49 | Poly-Tip V-MAX | 17 | 2550 | 2220 | 1915 | 245 | 186 | 138 | -0.5 | 0.1 | 0.3 | 0.0 |
| CCI | TNT | 53 | JHP | 17 | 2550 | 2132 | 1757 | 245 | 172 | 116 | -0.4 | 0.2 | 0.4 | 0.0 |
| CCI | TNT Green | 951 | TNT Green HP | 16 | 2500 | 2043 | 1642 | 222 | 148 | 96 | -0.5 | 0.1 | 0.0 | -0.6 |
| CCI | FMJ | 55 | FMJ | 20 | 2375 | 2063 | 1776 | 250 | 189 | 140 | -0.4 | 0.3 | 0.4 | 0.0 |
| CCI | Gamepoint | 52 | JSP | 20 | 2375 | 2051 | 1754 | 250 | 187 | 137 | -0.4 | 0.3 | 0.5 | 0.0 |
| Browning | BPR Performance Rimfire | B195117050 | Polymer Tip | 17 | 2550 | 2212 | 1901 | 245 | 185 | 136 | – | 0 | – | -0.3 |
Hornady Loads on the Rifle Chart Grid
Hornady lists its three 17 HMR loads on the standard rifle chart, which steps in 100 yard increments. Printed figures for these loads run to 200 yards, the path reads zero at 100 yards, and the chart prints no ballistic coefficient for them.
| Brand | Load | SKU | Bullet Weight (gr) | Vel. Muzzle (fps) | Vel. 100 yd (fps) | Vel. 200 yd (fps) | Energy Muzzle (ft-lb) | Energy 100 yd (ft-lb) | Energy 200 yd (ft-lb) | Path Muzzle (in) | Path 100 yd (in) | Path 200 yd (in) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hornady | NTX | 83171 | 15.5 | 2525 | 1830 | 1291 | 219 | 115 | 57 | -1.5 | 0 | -10 |
| Hornady | V-MAX | 83170 | 17 | 2550 | 1902 | 1379 | 245 | 137 | 72 | -1.5 | 0 | -8.5 |
| Hornady | XTP | 83172 | 20 | 2375 | 1755 | 1274 | 250 | 137 | 72 | -1.5 | 0 | -9.9 |
Velocity: One Load Stands Clear of the Pack
CCI’s VNT is the pace setter, at 2,650 fps from the muzzle and still 2,070 fps at 100 yards, the highest figure in that column as well. Behind it sits a crowded 2,550 fps group of 17 grain loads from CCI, Remington, Winchester, Hornady and Browning. The five 20 grain loads all print an identical 2,375 fps at the muzzle, and the lightest bullet here, Winchester’s 15.5 grain Varmint LF, also starts at 2,550 fps.
Energy: Modest at the Muzzle, Thin by 200 Yards
Muzzle energy tops out at 269 ft-lb for the CCI VNT, with the 20 grain loads next at 250 ft-lb apiece. The fall is steep: by 100 yards the VNT leads with 162 ft-lb and most 17 grain loads sit between 116 and 138 ft-lb. Only Winchester and Hornady print figures at 200 yards, where the Super X holds the most energy at 75 ft-lb and the NTX the least at 57 ft-lb.
Trajectory and Bullet Drop
Every maker in this chart publishes a bullet path, but the zeros differ, so each table keeps its maker’s own basis. On the published paths that read zero at 100 yards, drop at 150 yards is mild: the Remington AccuTip-V and Winchester Varmint HV print -2.6 in and the Federal V-Max prints -2.7 in. At 200 yards the Winchester Varmint HV and Hornady V-MAX both print -8.5 in, while the Hornady NTX falls furthest at -10 in.
Wind Drift in a 10 mph Crosswind
Federal and Remington print drift for a 10 mph crosswind on their 150 yard grid, and Winchester prints it out to 200 yards. At 150 yards the Remington JHP drifts most at 10.5 in, while the AccuTip-V and the Winchester Varmint HV tie for least at 8 in. Winchester’s figures keep growing past that point, reaching 17.1 in at 200 yards for the light Varmint LF, against 15.3 in for the Varmint HV.
Bullet Weights and Styles
Four weights appear: 15.5, 16, 17 and 20 grains, with the 17 grain polymer tip and hollow point loads making up most of the chart. The 20 grain group trades speed for weight and prints the same 2,375 fps and 250 ft-lb at the muzzle from four different makers. CCI’s 16 grain TNT Green is the chart’s lead free hollow point, and its FMJ and Gamepoint loads are the small game entries, built for limited meat damage and controlled expansion.
Coverage, Duplicates and Exclusions
The stored library holds 22 listings for this cartridge. CCI prints one identical set of figures behind three of them, the VNT (959CC), the VNT Pour Pack (923CC) and the A17 (949CC), so that row appears once. Federal likewise prints identical figures for its Champion BYOB and its Varmint & Predator TNT loads. One Aguila listing is held without usable published muzzle figures and appears in no table. Loads for the 17 WSM, 17 Mach 2 and 17 Hornet are different cartridges and are excluded.
Frequently Asked Questions
What is the fastest 17 HMR load in this chart?
CCI’s VNT, part 959CC, is fastest at 2,650 fps at the muzzle, and it is also quickest at 100 yards with 2,070 fps. CCI prints the same figures for its VNT Pour Pack and A17 loads.
How much does a 17 HMR drop at 150 yards?
On the published paths zeroed at 100 yards, drop at 150 yards runs from -2.6 in for the Remington AccuTip-V and Winchester Varmint HV to -3.1 in for the Winchester Super X. On a 50 yard zero the same distance shows -3 to -4 in, depending on the load.
How much does a 17 HMR drop at 200 yards?
Only Winchester and Hornady print paths that reach 200 yards. The Winchester Varmint HV and Hornady V-MAX both print -8.5 in there, the Winchester Super X and Hornady XTP print -9.9 in, and the Hornady NTX prints -10 in.
Which load keeps the most energy at 100 yards?
The CCI VNT, with 162 ft-lb at 100 yards. The next best figures at that distance are 140 ft-lb, printed by both the CCI FMJ and the Winchester Super X, then 138 ft-lb from the CCI V-MAX.
Why are the loads split into four tables?
Each maker publishes a different distance grid: Federal and Remington stop at 150 yards, Winchester steps to 200 yards in 25 yard increments, CCI and Browning stop at 100 yards, and Hornady steps in 100 yard increments to 200 yards. Grouping the loads by grid keeps every table full instead of stretching any load past the figures its maker prints.
What muzzle figures do the 20 grain loads print?
All five 20 grain loads print 2,375 fps and 250 ft-lb at the muzzle: the CCI FMJ and Gamepoint, the Remington Jacketed Soft Point, the Winchester Super X and the Hornady XTP.
Does CCI publish velocities for handguns?
Yes. CCI’s chart also prints a handgun velocity for each of its loads, from 2,140 fps for the VNT down to 1,830 fps for the FMJ and Gamepoint. Those handgun figures are kept out of the rifle tables above.
Is the 17 WSM included in this chart?
No. The 17 WSM, the 17 Mach 2 and the 17 Hornet are separate cartridges with their own stored loads, and none of their figures are mixed into these 17 HMR tables.
Why is there no Aguila load in the tables?
The library holds one Aguila 17 HMR listing, a 20 grain jacketed hollow point, but its stored record carries no usable published muzzle velocity or energy figure. With nothing reliable to print, it is left out of every table.
Which load drifts least in the wind at 150 yards?
Among the loads with published 10 mph crosswind figures at 150 yards, the Remington AccuTip-V drifts least at 8 in. The Remington Jacketed Hollow Point drifts most at that distance, at 10.5 in.
