50 Caliber Muzzleloader Ballistics

A fifty caliber inline muzzleloader lives or dies on its powder charge, so this page charts five popular sabot bullets at three charge levels each and shows exactly what every step up in powder buys. Velocity, energy and trajectory run from the muzzle to 200 yards on a 100 yard zero, and a factory chart covering six Hornady sabot loads to 250 yards follows below it.

50 Caliber Muzzleloader Ballistics Chart by Bullet and Powder Charge

BulletBC (G1)Powder ChargeVel. Muzzle (fps)Vel. 50 yd (fps)Vel. 100 yd (fps)Vel. 150 yd (fps)Vel. 200 yd (fps)Energy Muzzle (ft-lb)Energy 50 yd (ft-lb)Energy 100 yd (ft-lb)Energy 150 yd (ft-lb)Energy 200 yd (ft-lb)Traj. 50 yd (in)Traj. 100 yd (in)Traj. 150 yd (in)Traj. 200 yd (in)
220 gr Red Hot Sabot0.274100 gr FFg or Pyrodex171815951481137612821442124310729258031.230.00-5.22-14.70
220 gr Red Hot Sabot0.274120 gr Pyrodex Pellets1803167615561445134315881371118210208811.060.00-4.70-13.53
220 gr Red Hot Sabot0.274150 gr Pyrodex Pellets21582015187717461622227519821721148912850.570.00-3.02-8.87
250 gr Red Hot Sabot0.189100 gr FFg or Pyrodex15901428128711701082140311329197606501.600.00-6.89-19.75
250 gr Red Hot Sabot0.189120 gr Pyrodex Pellets168715151362123111281580127410298417061.420.00-5.93-18.55
250 gr Red Hot Sabot0.189150 gr Pyrodex Pellets2013181616331466132022491831148011939660.810.00-4.15-12.25
260 gr Jacketed Sabot0.166100 gr FFg or Pyrodex15631378122311061023141010958637066041.750.00-7.49-21.80
260 gr Jacketed Sabot0.166120 gr Pyrodex Pellets1647139912001064975156611298316545491.700.00-7.53-22.06
260 gr Jacketed Sabot0.166150 gr Pyrodex Pellets194916611410120910702193159211488446601.100.00-5.35-16.35
300 gr Red Hot Sabot0.207100 gr FFg or Pyrodex14781342122511301058145511999998517461.870.00-7.66-21.81
300 gr Red Hot Sabot0.207120 gr Pyrodex Pellets1694153613931268116419111570129210709031.360.00-5.69-16.84
300 gr Red Hot Sabot0.207150 gr Pyrodex Pellets19041730156914221293241419941640134811140.960.00-4.56-13.21
310 gr Lead Sabot0.148100 gr FFg or Pyrodex147513351215112010481497122610168647561.900.00-7.74-22.10
310 gr Lead Sabot0.148120 gr Pyrodex Pellets1551135311931077997165612619807996841.840.00-7.79-22.56
310 gr Lead Sabot0.148150 gr Pyrodex Pellets1850161514091236110723551796136610528441.190.00-5.44-16.41

The curves above follow the five bullets on the heaviest charge in the chart, three pellets totalling 150 grains, where the spread between bullet weights is widest.

See also  25-06 Bullet Drop Chart - 25-06 Ballistics

Charge Weight Drives the Whole Chart

Powder charge is the single biggest lever in these figures. The 250 grain bullet leaves at 1,590 fps on 100 grains of loose powder, climbs to 1,687 fps on 120 grains of pellets and jumps to 2,013 fps on 150 grains of pellets, while its muzzle energy rises from 1,403 ft-lb to 2,249 ft-lb across the same three steps. Every bullet in the chart gains speed at every distance when the charge grows.

The Lightest Bullet Is the Fastest

At 220 grains, the lightest bullet here pairs the highest ballistic coefficient in the chart, 0.274, with the top speeds at every charge. On 150 grains of pellets it starts at 2,158 fps, still carries 1,622 fps at 200 yards and keeps 1,285 ft-lb at that range, more retained energy than any heavier bullet manages there. Its flight is also the flattest, ending just 8.87 inches low at 200 yards.

Heavy Bullets Win at the Muzzle, Not Downrange

The 300 grain bullet on the full pellet charge posts the highest muzzle energy in the chart at 2,414 ft-lb, and the 310 grain lead bullet follows at 2,355 ft-lb. Distance reverses the order, because the heavy, low coefficient bullets shed speed quickly. By 200 yards the 300 grain load is down to 1,114 ft-lb and the 310 grain load to 844 ft-lb, both behind the lighter 220 grain load.

Reading the Trajectory Columns

Every trajectory figure assumes a 100 yard zero, so each bullet sits exactly on the line of sight at 100 yards. At 50 yards the bullets strike between 0.57 and 1.90 inches high, then fall below the line of sight past the zero. The drop at 200 yards runs from 8.87 inches for the fastest load to 22.56 inches for the 310 grain bullet on the middle charge, which is why range estimation matters so much with this caliber.

See also  6.5 Creedmoor vs 243 Ballistics Chart

One Exception in the Middle Charge

The 260 grain jacketed bullet is the odd row in the chart. Its 120 grain pellet load starts faster than its 100 grain loose powder load, 1,647 fps against 1,563 fps, yet the printed figures show it easing behind by 100 yards, 1,200 fps against 1,223 fps, and trailing at 200 yards as well. For every other bullet the middle charge stays ahead of the light charge at all distances.

Hornady Factory Ballistics Chart

Hornady publishes full figures for six of its fifty caliber sabot loads, all developed in a stock T/C Omega inline muzzleloader with 150 grain charges. Four 250 grain bullets share one set of numbers and two 300 grain bullets share another, and the chart runs to 250 yards with the rifle sighted 3 inches high at 100 yards.

BrandLoadItemPowder Charge (gr)Vel. Muzzle (fps)Vel. 50 yd (fps)Vel. 100 yd (fps)Vel. 150 yd (fps)Vel. 200 yd (fps)Vel. 250 yd (fps)Energy Muzzle (ft-lb)Energy 50 yd (ft-lb)Energy 100 yd (ft-lb)Energy 150 yd (ft-lb)Energy 200 yd (ft-lb)Energy 250 yd (ft-lb)Traj. Muzzle (in)Traj. 50 yd (in)Traj. 100 yd (in)Traj. 150 yd (in)Traj. 200 yd (in)Traj. 250 yd (in)
HornadyMonoFlex Lock-N-Load Speed Sabot67269150225020311852168415291389273522901904157412971070-1.51.83.01.7-2.7-11.0
HornadySST-ML Lock-N-Load Speed Sabot67270150225020311852168415291389273522901904157412971070-1.51.83.01.7-2.7-11.0
HornadySST-ML Low Drag Sabot67273150225020311852168415291389273522901904157412971070-1.51.83.01.7-2.7-11.0
HornadyMonoFlex High Speed Low Drag Sabot67274150225020311852168415291389273522901904157412971070-1.51.83.01.7-2.7-11.0
HornadySST-ML Low Drag Sabot67263150213019741826168615541433302225972221189316091368-1.51.93.01.6-2.9-11.1
HornadySST-ML Lock-N-Load Speed Sabot67271150213019741826168615541433302225972221189316091368-1.51.93.01.6-2.9-11.1

Two Weights, Two Shared Curves

The four 250 grain bullets, items 67269, 67270, 67273 and 67274, cover the SST-ML and MonoFlex names in Lock-N-Load Speed Sabot and Low Drag Sabot dress, and Hornady prints one identical curve for all of them: 2,250 fps and 2,735 ft-lb at the muzzle, 1,852 fps at 100 yards and 1,389 fps with 1,070 ft-lb at 250 yards. The two 300 grain bullets, items 67263 and 67271, likewise share a single curve.

See also  6.5 Grendel vs 6.8 SPC Ballistics Chart

Where the 300 Grain Load Takes Over

The heavier pair starts slower at 2,130 fps but posts the highest muzzle energy on the factory chart at 3,022 ft-lb, and it leads on energy at every distance from there. On velocity the 250 grain group stays in front until 150 yards, where the two groups are nearly level, and the 300 grain bullets move ahead by 200 yards, holding 1,433 fps and 1,368 ft-lb out at 250 yards.

Sighting 3 Inches High at 100 Yards

Both weight groups ride the same path in the factory chart, crossing 3.0 inches above the line of sight at 100 yards, slipping to about 2.8 inches low at 200 yards and finishing near 11 inches low at 250 yards. Hornady pairs that sighting with a 6 inch shooting window to 200 yards on a 150 grain charge, which is the practical hunting takeaway from the trajectory columns.

Lehigh Defense 240 Grain Component Load

Lehigh Defense publishes its 240 grain Controlled Fracturing muzzleloader bullet, a .452 inch copper bullet with a G1 ballistic coefficient of 0.18, as component load data behind Blackhorn 209 in a 26 inch test barrel with a 209 primer. Only muzzle velocity is published, at two charge levels, so the load sits in this short listing rather than in a full table.

BrandLoadSKUPowder ChargeTest Barrel (in)Muzzle Velocity (fps)
Lehigh Defense240 gr Controlled Fracturing (.452 in bullet), Blackhorn 209 starting charge02452240SPM50 gr261,206
Lehigh Defense240 gr Controlled Fracturing (.452 in bullet), Blackhorn 209 maximum charge02452240SPM120 gr262,099

Listings That Publish No Figures

A few fifty caliber muzzleloader products carry no ballistics at all. Hornady lists a 290 grain Bore Driver FTX, item 67713, and prints no velocity, energy or trajectory figures for it. The stored Federal and Remington muzzleloading listings likewise publish no velocities, Nosler lists a 300 grain Ballistic Tip muzzleloader bullet without a ballistics table, and Barnes stores no muzzleloader ballistics in the library.

Frequently Asked Questions

What muzzle velocity does a 50 caliber muzzleloader produce?

It depends on the bullet and charge pairing. Across the fifteen combinations in the main chart, muzzle velocity runs from 1,475 fps for the 310 grain lead bullet on 100 grains of loose powder to 2,158 fps for the 220 grain bullet on 150 grains of pellets.

Which load in the chart hits hardest at the muzzle?

The 300 grain bullet on 150 grains of pellets, with 2,414 ft-lb of muzzle energy. The fastest load is a different one: the 220 grain bullet on the same charge, at 2,158 fps.

How much does a 50 caliber muzzleloader bullet drop at 200 yards?

With a 100 yard zero, the bullets in the main chart strike between 8.87 and 22.56 inches below the line of sight at 200 yards. The flattest path belongs to the 220 grain bullet on 150 grains of pellets.

Where does the bullet strike at 50 yards with a 100 yard zero?

High, in every row of the main chart. The bullets cross between 0.57 and 1.90 inches above the line of sight at 50 yards before settling onto the zero at 100 yards.

How much energy is left at 200 yards?

Retained energy at 200 yards runs from 549 ft-lb for the 260 grain bullet on the middle charge to 1,285 ft-lb for the 220 grain bullet on 150 grains of pellets. Most combinations hold between roughly 650 and 1,100 ft-lb at that range.

What powder charges does the main chart cover?

Three charge levels for each bullet: 100 grains of loose FFg or Pyrodex powder, 120 grains of Pyrodex pellets and 150 grains of Pyrodex pellets. Stepping up a level raises velocity and energy at every distance for nearly every bullet.

Does a heavier muzzleloader bullet always hit harder at 200 yards?

No. The 300 grain bullet leads on muzzle energy at 2,414 ft-lb, yet at 200 yards it holds 1,114 ft-lb, less than the 1,285 ft-lb kept by the lighter and faster 220 grain bullet on the same charge.

What velocity does the Hornady 250 grain sabot load produce?

Hornady prints 2,250 fps at the muzzle for all four of its 250 grain sabot bullets on a 150 grain charge. The load still carries 1,852 fps at 100 yards and 1,389 fps at 250 yards.

How fast is the Lehigh Defense 240 grain muzzleloader bullet?

Lehigh Defense publishes muzzle velocity only: 1,206 fps behind the 50 grain Blackhorn 209 starting charge and 2,099 fps behind the 120 grain maximum charge. Both figures come from a 26 inch test barrel.

Why does the Hornady chart sight the rifle 3 inches high at 100 yards?

That sighting keeps the bullet inside a 6 inch window all the way to 200 yards on a 150 grain charge, per the note printed with the factory chart. The bullet then falls to about 11 inches low at 250 yards.
